BF-2308-6
System details
- Type
- Linear Joint
- Element
- Wall
- Substrate
- Speedpanel / Korok
- Minimum Substrate Thickness
- 100 mm
- FRL / FRR
- -/240/180
- Trade
- Construction (Linear Gaps / Blank Seals)
- Fire Rating
- 240
Fire-stopping products
Application dimensions
- Max Width
- 200 mm
- Max Length
- -1 mm
- Aperture
- 200 gap x Unlimited length mm
- Sealant Depth
- Fill Gaps mm
- Sealant Fillet
- 0 mm
Specimen size & details
100 mm thick double layer of BOSS Batt™ friction fitted into an aperture up to 200 mm gap x Unlimited length, coated with 1 mm DFT BOSS Ablative Coating™. A bead of sealant is applied to the edges of the batt and the separating element to both sides.
