BF-2616-25
System details
- Type
- Linear Joint
- Element
- Floor
- Substrate
- Concrete Slab
- Minimum Substrate Thickness
- 175 mm
- FRL / FRR
- -/240/120
- Trade
- Construction (Linear Gaps / Blank Seals)
- Fire Rating
- 240
Fire-stopping products
Application dimensions
- Max Width
- 60 mm
- Max Length
- 60 mm
- Aperture
- 60 mm
- Sealant Depth
- 30 mm
Specimen size & details
Linear gap seal up to 60 mm wide, with 30 mm deep sealant applied flush with the top face of the floor, backed by three 20 mm PEF backing rods. System installed to one side only of a 175 mm thick floor system.
